Description

🔹 Overview
• Advanced Italian-made dental X-ray device for precise imaging.
• Compact design with flexible extension arm for easy positioning.
• Delivers high-quality imaging with ultra-low radiation leakage for maximum safety.
🔹Electrical Features
• Power Supply: 230V ±10%
• Frequency: 50Hz
• Current: 5A
🔹X-Ray Tube Features
• Tube: CEI OCX 65 G
• Focal Spot: 0.7 mm
• Anode Material: Tungsten
• Extension Arm: 500–900 mm (Max: 1980 mm)
• Total Filtration: ≥ 2 mm Al eq.
🔹Radiological Features
• Min. Focus-Skin Distance: 200 mm
• Irradiated Area: Ø 55 mm
• Leakage @1m: <0.25 mGy/h
• High Voltage: 70 kVp
• Anode Current: 8 mA
• Exposure Time: 0.04 – 2.00 s
• Duty Cycle: 1:60
• Control Logic: Deadman

Upgrade your diagnostics with the ORIX 70 New Edition – Italian Dental X-Ray Unit.
👉 Contact us today for pricing and warranty details!
